One side coated silicone fabric is made of woven fiberglass fabrics that have been coated on one side with silicone rubber.It is quite similar to PTFE Coated Glass Fabrics: good temperature resistance and electric resistance. Apart from these characteristics, silicone coated glass fabrics are more flexible and has a non-slip surface, unlike PTFE.
These silicone fabric is widely used for manufacturing of removable,reusable insulation pads,jackets,Matresses for Valves,Turbines,
Equipment requiring frequent inspection and maintenance in high temperature and HVAC Chilled
water application.
Properties:
1.Ozone resistantce, anti-aging property, weather resistance
2.Stable size(coefficient of elongation), long service life(could reach 10 years) 3.Great insulating performance: high voltage load resistant, dielectric constant:3-3.2, puncture voltage 20~50 KV/MM 4.Excellent chemical resistance, good oil/water proof performance, easy to clean.
Applications:
– Foam manufacturing
-Insulating cloth/Liner
– Electrical insulation tapes
– Conveyor belts for industrial processes
– Safety curtains
The elasticity and flexibility are both very desirable, currently, it has been widely used for the pipe connecting in many industries like oil, chemical, cement and energy.
– Release and separator sheets
– Gasketing,and for packaging, food, printing, chemical and rubber industries
– Non-metallic compensator
The silicone coated glass cloth can be used to produce flexible joints which can prevent the pipe from being damaged by thermal expansion effect, due to its characteristics of high temperature resistant, anti-corrosive, anti-aging.
Main Specification:
| Model |
Thickness |
Breaking Strength (n/50mm) |
Bursting Strength (Mpa) |
Combustible |
width |
|
|
mm |
mil |
|||||
| YS-5015 |
0.15 |
6 |
1500/1200 |
2.0 |
≤25% |
0—1500mm |
| YS-5025 |
0.25 |
10 |
1800/1500 |
2.1 |
≤25% |
0—1500mm |
| YS-5040 |
0.40 |
16 |
2000/1600 |
2.2 |
≤25% |
0—1500mm |
| YS-5050 |
0.50 |
20 |
2200/1800 |
2.3 |
≤25% |
0—3000mm |
| YS-5060 |
0.60 |
24 |
2400/2200 |
2.4 |
≤25% |
0—3000mm |
| YS-5070 |
0.70 |
28 |
2500/2300 |
2.4 |
≤25% |
0—3000mm |
| YS-5080 |
0.80 |
31 |
2600/2400 |
2.5 |
≤25% |
0—3000mm |
| YS-5090 |
0.90 |
35 |
2800/2600 |
2.5 |
≤25% |
0—3000mm |
| YS-5100 |
1.00 |
40 |
3000/2800 |
2.6 |
≤25% |
0—3000mm |
| YS-5120 |
1.20 |
47 |
3400/3000 |
2.5 |
≤25% |
0—3000mm |
| YS-5150 |
1.50 |
59 |
3700/3300 |
2.8 |
≤25% |
0—3000mm |
| YS-5200 |
2.00 |
79 |
4200/3800 |
3.5 |
≤25% |
0—3000mm |
| YS-5300 |
3.00 |
118 |
6500/6200 |
5.0 |
≤25% |
0—1000mm |
silicone fabric
“”
